Tạo Real-Time Multiplayer Tic-Tac-Toe Scalable với Node.js, Socket.IO, và Redis

Tạo Real-Time Multiplayer Tic-Tac-Toe Scalable với Node.js, Socket.IO, và Redis

Trong tutorial này, chúng ta sẽ build real-time multiplayer Tic-Tac-Toe game dùng Node.js, Socket.IO, và Redis. Game cho phép hai players connect từ different browser tabs, take turns playing, và see real-time updates khi chơi. Chúng ta dùng Redis manage game state synchronization across multiple WebSocket servers, làm application scalable.

Cuối cùng, bạn sẽ có fully functional game với real-time capabilities và solid understanding cách dùng WebSockets và Redis build scalable real-time applications.

What You Will Learn

  • Cách dùng Socket.IO cho real-time communication.

  • Cách dùng Redis Pub/Sub synchronize game state across multiple clients.

  • Cách setup scalable WebSocket server architecture.

Prerequisites

Trước khi bắt đầu, ensure bạn có installed:

  • Node.js (v16 hoặc cao hơn)

  • Redis

  • Docker (optional, cho run Redis in container)

  • Basic knowledge JavaScript, Node.js, và WebSockets.

Mục lục

  • Project Overview

  • Step 1: Setting Up Your Development Environment

  • Step 2: Setting Up the Project

  • Step 3: Implementing the WebSocket Server with Redis

  • Step 4: Implement the React Frontend interface

  • Step 5: Running the Application

  • Step 6: Viewing Redis Messages in Real-Time

  • Demo

  • Conclusion

Project Overview

Chúng ta build real-time Tic-Tac-Toe game với features:

  • Hai players connect và play game.

  • Game board updates real-time across different browser tabs.

  • Game announce winner hoặc declare draw khi board full.

Chúng ta dùng:

  • Node.js với Socket.IO handle WebSocket connections.

  • Redis Pub/Sub manage game state synchronization across clients.

Step 1: Setting Up Your Development Environment

Installing Node.js

Ensure Node.js installed:

node -v

Nếu chưa có, download từ Node.js.

Installing Redis

Install Redis locally hoặc run Docker container.

macOS (Using Homebrew)

Đảm bảo Homebrew installed trước khi chạy commands:

brew install redis
brew services start redis

Verify Redis container running:

redis-cli ping

Bạn thấy:

PONG

Using Docker to Run Redis

docker run --name redis-server -p 6379:6379 -d redis

Check Redis running:

docker exec -it redis-server redis-cli ping

Step 2: Setting Up the Project

1. Create the Project Directory

mkdir tic-tac-toe
cd tic-tac-toe
npm init -y

2. Install Dependencies

npm install express socket.io redis dotenv

3. Create Environment Variables

Tạo file .env ở project root với contents:

PORT=3000
REDIS_HOST=localhost
REDIS_PORT=6379

Step 3: Implementing the WebSocket Server with Redis

Trong step này, setup WebSocket server handle real-time game interactions dùng Node.js, Socket.IO, và Redis. Server manage game state, handle player moves, ensure synchronization across multiple clients dùng Redis Pub/Sub.

Chúng ta break down mỗi section code để bạn hiểu exactly everything fits together.Server Code Explanation

Tạo file server.js thêm code sau:

import dotenv from 'dotenv';
import express from 'express';
import http from 'http';
import { Server } from 'socket.io';
import { createClient } from 'redis';
dotenv.config(); // Load environment variables from .env file
const app = express();
const server = http.createServer(app);
const io = new Server(server, {
    cors: {
        origin: "https://localhost:5173",
        methods: ["GET", "POST"],
    }
});
  • dotenv: Load env variables từ .env file giữ sensitive info như ports và keys secure.

  • express: Setup basic Express server handle HTTP requests.

  • http: Tạo HTTP server dùng Node's built-in http module, dùng với Socket.IO cho WebSocket communication.

  • Socket.IO: Library enable real-time, bidirectional communication giữa server và clients.

  • CORS Configuration: Allow cross-origin requests từ frontend chạy trên localhost:5173.

Tiếp, tạo Redis publisher và subscriber clients, thêm code vào server.js:

// Initialize Redis clients
const pubClient = createClient();
const subClient = createClient();
await pubClient.connect();
await subClient.connect();

Dùng Redis handle real-time data synchronization giữa connected clients.

  • pubClient: Publish messages (như game state updates).

  • subClient: Subscribe messages (listen updates).

  • connect(): Establish connection đến Redis server.

Trong paradigm này, một client publish updates, client kia subscribe updates. Giúp avoid blocking behavior, vì Redis clients ở subscribe mode chỉ receive messages.

Để subscribe Redis channels cho game updates, thêm code vào server.js:

// Subscribe to Redis channel for game updates
await subClient.subscribe('game-moves', (message) => {
    gameState = JSON.parse(message);
    io.emit('gameState', gameState);
});
  • subClient.subscribe: Listen messages trên channel game-moves.

  • Khi player mới make move, game state updated trong Redis, và all connected clients informed new state.

  • Parameter message chứa game state as string. Parse thành JavaScript object và broadcast updated state dùng Socket.IO.

Tiếp, define game state và functions, thêm code vào server.js:

// Define initial game state
let gameState = {
    board: Array(9).fill(null),
    xIsNext: true,
};
// Function to reset the game
function resetGame() {
    gameState = {
        board: Array(9).fill(null),
        xIsNext: true,
    };
}
  • gameState: Track current state của board và whose turn (xIsNext).

    • Board represented as array 9 cells (mỗi cell 'X', 'O', hoặc null).
    • Flag xIsNext determine player's turn.
  • resetGame(): Reset board và turn indicator về initial state, cho phép new game start.

Tiếp, handle WebSocket connections, thêm code vào server.js:

io.on('connection', (socket) => {
    console.log('New client connected:', socket.id);
    // Send current game state to newly connected client
    socket.emit('gameState', gameState);
  • io.on('connection') event triggered khi new client connects.

  • socket.id: Unique identifier cho each connected client.

  • Gửi ngay gameState cho new client để họ thấy current board.

Handle player moves, thêm code vào server.js:

// Handle player moves
socket.on('makeMove', (index) => {
    // Prevent move if cell already taken or game over
    if (gameState.board[index] || calculateWinner(gameState.board)) return;
    // Update board and switch turns
    gameState.board[index] = gameState.xIsNext ? 'X' : 'O';
    gameState.xIsNext = !gameState.xIsNext;
    // Publish updated game state to Redis
    pubClient.publish('game-moves', JSON.stringify(gameState));
    io.emit('gameState', gameState);
});
  • makeMove: Event triggered khi player click cell.

    • Validation: Check cell occupied hoặc game ended trước make move.

    • Updating Game State: Nếu move valid, update board và switch turns.

  • Updated game state thì:

    1. Published to Redis: Ensure all server instances stay in sync.

    2. Broadcasted to all clients: Immediately update game board cho all players.

Handle game restarts, thêm code vào server.js:

// Handle game restarts
socket.on('restartGame', () => {
    resetGame();
    io.emit('gameState', gameState);
});

Handle client disconnection, thêm code vào server.js:

socket.on('disconnect', () => {
    console.log('Client disconnected:', socket.id);
});
});

Cuối, process game logic, thêm functions vào server.js:

// Function to check if there's a winner
function calculateWinner(board) {
    const lines = [
        [0, 1, 2], [3, 4, 5], [6, 7, 8],
        [0, 3, 6], [1, 4, 7], [2, 5, 8],
        [0, 4, 8], [2, 4, 6]
    ];
    for (let [a, b, c] of lines) {
        if (board[a] && board[a] === board[b] && board[a] === board[c]) {
            return board[a];
        }
    }
    return null;
}
function isBoardFull(board) {
    return board.every((cell) => cell !== null);
}
  • calculateWinner(): Check winning combination trên board.

  • isBoardFull(): Check all cells filled, indicate draw.

Step 4: Implement the React Frontend interface

Trong step này, build simple interactive React frontend cho Tic-Tac-Toe game. Frontend cho phép players connect WebSocket server, make moves, see game board update real-time.

Trong App.jsx, thêm code:

import React, { useEffect, useState } from 'react';
import io from 'socket.io-client';
const socket = io('https://localhost:3000');
function App() {
    const [gameState, setGameState] = useState({
        board: Array(9).fill(null),
        xIsNext: true,
        winner: null
    });
    useEffect(() => {
        socket.on('gameState', (state) => {
            setGameState(state);
        });
        return () => socket.off('gameState');
    }, []);
    const handleClick = (index) => {
        if (gameState.board[index] || gameState.winner) return;
        socket.emit('makeMove', index);
    };
    const renderCell = (index) => (

    );
    return (


Multiplayer Tic-Tac-Toe

{[...Array(9)].map((_, i) => renderCell(i))}
); } export default App;

Tóm tắt React app breakdown:

  • WebSocket Connection:

    • Frontend establish connection đến server dùng socket.io-client.
  • State Management:

    • Game state (gameState) managed với React's useState bao gồm:

      • Board (9 cells).

      • Flag xIsNext indicate current player's turn.

      • Winner status.

  • Real-Time Updates:

    • useEffect hook:

      • Listen gameState updates từ server.
      • Update local game state khi detect changes.
      • Cleanup WebSocket listener khi component unmount.
  • Handling Player Moves:

    • handleClick function:

      • Check cell occupied hoặc game has winner trước allow move.
      • Gửi makeMove event đến server với clicked cell index.
  • Game Board Rendering:

    • renderCell function tạo button cho each cell trên board.

    • Board displayed dùng 3x3 grid.

  • Restart Game:

    • "Restart Game" button emit restartGame event reset game board cho all players.
  • User Interface:

    • Simple interactive layout cho players take turns và see updates real-time.

Step 5: Running the Application

Starting the Backend

Start backend server, mở terminal mới chạy:

cd tic-tac-toe
npm start

Starting the Frontend

Start React frontend server, mở terminal mới chạy commands (không dùng terminal backend vì cần cả hai chạy simultaneously):

cd tic-tac-toe-client
npm run dev

Accessing the Game

Mở browser navigate to:

https://localhost:5173

Step 6: Viewing Redis Messages in Real-Time

Khi game running, bạn view Redis messages xem real-time game state updates.

Mở terminal chạy:

redis-cli SUBSCRIBE game-moves

Hiển thị game updates:

1) "message"
2) "game-moves"
3) "{\"board\":[\"X\",null,\"O\",null,\"X\",null,null,null,null],\"xIsNext\":false}"

Mỗi lần move made hoặc game state changes, server publish updated game state đến channel game-moves. Dùng redis-cli, monitor updates real-time, as game being played.

Demo

Trong demo, bạn thấy Tic Tac Toe game chạy locally, demonstrate real-time updates khi players take turns.

Gameplay showcase features như turn switching, board updates, game state announcements (winner hoặc draw). Highlight game leverage WebSocket communication cung cấp smooth, interactive experience.

Kết luận

Chúc mừng, bạn successfully built real-time multiplayer Tic-Tac-Toe game dùng Node.js, Socket.IO, và Redis. Đây là những gì bạn học:

  • Real-time WebSocket communication dùng Socket.IO.

  • Game state management dùng Redis Pub/Sub.

  • Building responsive front-end với React.

Next Steps

  • Add player authentication.

  • Implement chat feature.

  • Deploy application to cloud provider cho scalability.

Happy coding!
